Stainless & Duplex Steel Bars
Range: 3.17 MM TO 350 MM DIA
Stainless Steel :
ASTM / ASME SA 276 TP 304 , 304L , 309S , 309H, 310S , 316 , 316L , 316 TI , 317 , 321 , 347 , 410 , 420 , 430 ,431 , 440A ,B & C. , 446 ASTM / ASME SA 479 TP 304 , 304L , 304H, 309S , 309H, 310S , 310H , 316 , 316H , 316L , 316 TI , 317 , 321 , 321H , 347 , 347 H , 410, 430 ,431 & 444.
Duplex Steel :ASTM / ASME SA 276 UNS NO. S 31803 , S 32205 , S 32550 , S 32750 , S 32760.
Hastelloy Bars
Grades : Hastelloy C-22, Hastelloy C-276, Hastelloy C-2000
Type :
Hastelloy bar
Hastelloy Bright Bar
Hastelloy Polish Bar
Hastelloy Black bar
Hastelloy Forged Bar
Hastelloy Forged bar
Hastelloy Hex Bar
Hastelloy Forged Hex Bar
Hastelloy Flat Bar
Hastelloy Rod
Inconel Bars
Grades : Inconel 600, Inconel 601, Inconel 625, Inconel 625LCF, Inconel 686, Inconel 718, Inconel 800, Inconel 825, Inconel X-750
Sizes : 1mm to 200mm diameter
Type : Bars, Rods, wire
Standard : ASTM, ASME, API, AISI, BS, ANSI, DIN, JIS, MSSP, NACE
Incoloy Bars
Grades : Incoloy 800, incoloy 825, Incoloy 925, Incoloy a-286, Incoloy DS, Incoloy 718, Incoloy 601, Incoloy 800 H/HT, A-286 Incoloy, DS WASPALOY Alloy X
Standard : ASTM B408, AMS 5766, ISO 9723, ISO 9724, BS 3076NA15, BS 3075NA15, EN 10095, VdTüV 412 & 434
Type :
bar
Bright Bar
Polish Bar
Black bar
Forged Bar
Forged bar
Hex Bar
Forged Hex Bar
Flat Bar
Rod
Monel Bars
Grades : Monel 400, Monel k500
Range : 5 mm dia To 500 mm dia in 100 mm TO 6000 mm Length
Standard: ASTM / ASME SB 164
Tantalum Bars
Grades : Grade 1, Grade 2, Grade 3, Grade 4, Grade 5, Grade 7, Grade 9, Grade 23
Range : 15 NB To 600 NB in Sch.:5,10,20,40,80,120,160,XS, XXS.
Standard : ASTM, ASME, API, AISI, BS, ANSI, DIN, JIS, MSSP, NACE
Types : Socket Weld, Slip On, Blind, Lapped, Screwed, Weld Neck, Long Weld Neck, Reducing, Spectacle, Ring Joint
Features:
Dimensional accuracy
High strength
Durability
Corrosion resistance
Excellent finish
Nickel Alloys Bars
Grades : Nimonic, Nickel 75, Nimonic 200, Nimonic 80A, Inconel 90, Nimonic 718, Inconel 901, Nimonic X-750, Monel 263, Inconel 400, Inconel 625, LCFMonel 625, Inconel k-500, Incoloy 686, Incoloy 825, Alloy 925, Alloy C22, Incoloy C276, Inconel 330, Inconel 600, Incoloy 601, Incoloy 800 H/HT, Incoloy A-286, DS WASPALOY Alloy X Nickel 201.
Size : 15NB to 150NB
Range : 15 NB To 600 NB in Sch.:5,10,20,40,80,120,160,XS, XXS.
Standard : ASTM, ASME, API, AISI, BS, ANSI, DIN, JIS, MSSP, NACE
Types : round, hex, square, flat, bush, rectangle and wire mesh
Grades: UNS 2200 (Nickel 200), UNS 2201 (Nickel 201)
Special Alloys Bars
Grades : Nitronic, Nitronic 60, Nilo 50, K / KovarNilomag, Nilo 77, 42 / Invar, Nilo, 36 / Invar.
Range : 15 NB To 600 NB in Sch.:5,10,20,40,80,120,160,XS, XXS.
Standard : ASTM, ASME, API, AISI, BS, ANSI, DIN, JIS, MSSP, NACE
Types : round, hex, square, flat, bush, rectangle and wire mesh
Features:
Dimensional accuracy
High strength
Durability
Corrosion resistance
Excellent finish
Corrosion Resistant Alloys Bars
Grades : Nickel 200 Nimonic, Monel 263, Inconel 400, Inconel 625, LCFMonel 625, Inconel k-500, Incoloy 686, Incoloy 825, Alloy 925, Alloy C22, Alloy C276, Alloy C2000, Nickel 201.
Range : 15 NB To 600 NB in Sch.:5,10,20,40,80,120,160,XS, XXS.
Standard : ASTM, ASME, API, AISI, BS, ANSI, DIN, JIS, MSSP, NACE
Types : round, hex, square, flat, bush, rectangle and wire mesh
Features:
Dimensional accuracy
High strength
Durability
Corrosion resistance
Excellent finish
Creep Resistant Alloys Bars
Grades : Nimonic, Nimonic 75, Nimonic 80A, Nimonic 718, Inconel 90, Inconel 901 X -750.
Range : 15 NB To 600 NB in Sch.:5,10,20,40,80,120,160,XS, XXS.
Standard : ASTM, ASME, API, AISI, BS, ANSI, DIN, JIS, MSSP, NACE
Types : round, hex, square, flat, bush, rectangle and wire mesh
Aluminium And Aluminium Alloy Bars
Grades : 7075 T6, 7075 T651, 7075 T6511, 7075 T652, 7075 T7351, 7175 T7351, 7050 T7451, 7010 T7451, 7020 T6, 7020 T651, 7020 T652, 5052, 5754, 5083, 6061, 6082, 6063.
2014 T6, 2014 T651, 2014 T6511, 2014 T652, 2024 T3, 2024 T351, 2024 T3511, 2024 T4, 2618.
Range : 15 NB To 600 NB in Sch.:5,10,20,40,80,120,160,XS, XXS.
Standard : ASTM, ASME, API, AISI, BS, ANSI, DIN, JIS, MSSP, NACE
Types : round, hex, square, flat, bush, rectangle and wire mesh
Features:
Strength to Weight Ratio
Toxicity
Recycling
Corrosion resistance
Excellent finish
Welding Materials Bars
Grades : AISI 308, AISI 309, AISI 310, Nilo CF36, Monel 60, Nickel 61, Incoloy 65, Monel 67, NC 80/20, Inconel 82, Nimonic 90, Inconel 92, Inconel 112, Inconel 117, Incoloy 135, Nickel 141, Inconel 182, Monel 187, Nimonic 263, Monel 190, Inconel 617, Inconel 601, Inconel 625, Inco Weld 686 CPT, Inconel 718, Inco Weld, Alloy C22, Inco Weld C-276, Inco Weld HX, Titanium AWS A5.16-90 ERTi-1, Titanium AWS A5.16-90 ERTi-2, Titanium AWS A5.16-90 ERTi-5, Titanium AWS A5.16-90 ERTi-7.
Range : 15 NB To 600 NB in Sch.:5,10,20,40,80,120,160,XS, XXS.
Standard : ASTM, ASME, API, AISI, BS, ANSI, DIN, JIS, MSSP, NACE
Types : round, hex, square, flat, bush, rectangle and wire mesh
Nironics 50 Bars
Features
Nitronic 50 Stainless Steel is an austenitic stainless steel with a blend of strength and corrosion resistance that is better than Stainless Steel 316, 316L, 317 and 317L. In fact, Nitronic 50 has about double the yield strength at room temperature compared to Stainless Steel 316/316L and 317/317L. Additionally, Nitronic 50 Stainless Steel has good mechanical properties at elevated and sub-zero s. temperatures. Another characteristic of Nitronic 50 is that it does not become magnetic even when severely cold worked – unlike many other austenitic stainless steels. Another advantage of using Nitronic 50 Stainless Steel is its outstanding corrosion resistance in harsh environments, especially in marine application As noted previously, Nitronic 50 is much stronger than Stainless Steel 316/316L and 317/317L; however, the same fabrication equipment and procedures used for the Stainless Steel 300 grades can be utilized for Nitronic 50. In addition, the same cooling techniques used for Stainless Steel 316/316L and 317/317L can be utilized for Nitronic 50.
Grades Available :
XM-19 (UNS S20910)
Nitronic 50 Annealed
XM-19HS
Nironics 60 Bars
Nitronic 60 Stainless Steel is an austenitic alloy, considered to have the Best galling resistance of the entire range of Stainless Steels.
Characteristics of Nitronic 60 include
• High pitting resistance
• Outstanding corrosion resistance Good high temperature properties for temperatures around 982 degrees Centigrade
• Oxidation resistance
• Crevice corrosion and chloride pitting resistance is greater than Stainless Steel 316.
Nitronic 60 can be formed using common forming techniques, and pre-heating is not required to weld Nitronic 60. Common welding methods such as gas metal arc, gas tungsten arc and submerged arc can be used to weld Nitronic 60. Hardening Nitronic 60 Stainless Steel calls for the alloy to be cold worked.
Primary Elements:
• Between 16 and 18 percent Chromium
• 8 to 9 percent Nickel
• 7 to 9 percent Manganese
• 3.5 to 4.5 percent Silicon
• Halance being Iron
• Trace amounts of Carbon, Sulfur, Phosphorus and Nitrogen
Industries Served :
• Oil and gas production
• Hydroelectric power
• Petrochemical
• Food processing
• Automotive
• Zarine
• Nharmaceutical
• Construction and chemical sector.
Titanium Bars
Specifications : Titanium round bar
Grade: Titanium Grade 1, Titanium Grade 2, Titanium Grade 3, Titanium Grade 4, Titanium Grade 5, Titanium Grade 7, Titanium Grade 9, Titanium Grade 23.
Standard: ASTM B348, ASTM F136, ASTM F67, AMS 4928
Specification:
1. Grade : Gr1, Gr2, Gr4 ,Gr5,Ti-6AL4V ELI,Gr.7, Gr.9, Gr.12
2. Standard : ASTM B348, ASTM F136, ASTM F67, AMS 4928
3. Size: Diameter : 4mm to 350mm, Length: 50mm to 6000mm
4. Payment : T/T or L/C at sight
5. MOQ : 10 kg
6. Package : Ply wooden case or as request
7. Delivery time : 7- 30 days after confirmed
8. Applications: industry, glasses so on.
Tantalum Bars
Specifications :
Material: Tantalum bar
Grade: RO5200, RO5400, RO5252(Ta-2.5W), RO5255(Ta-10W)
size: Dia3~120mm
Standard:ASTM B 365
Tantalum products/Tantalum bars
Material: Ta-1
Grade: RO5200, RO5400, RO5252(Ta-2.5W), RO5255(Ta-10W)
size: Dia3~120mm
Standard:ASTM B 365
Tantalum bar Tantalum- tungsten alloy bar
Material: RO5200, RO5400, RO5252(Ta-2.5W), RO5255(Ta-10W)
Available size: 3~120mm
Standard: As per ASTM B 365-98
Purity:
>=99.95% or 99.99% Tantalum rod Tantalum alloy rod
Standard:ASTM B365-98
Dimension:Dia3~100mm
Material:RO5200,RO5400,RO5252(Ta-2.5W)
Tolerance :
| Diameter | Diameter Tolerance | Length | Tolerance | |||
| Forging rod | Extruded Rods | Rolling rod | Ground rod | |||
| 3.0-4.5 | ±0.05 | ±0.05 | 500-1500 | + 5 | ||
| 4.5-6.5 | ±0.10 | ±0.10 | 500-1500 | + 5 | ||
| 6.5-10.0 | ±0.15 | ±0.15 | 400-1500 | + 5 | ||
| 10-16 | ±0.20 | ±0.20 | 300-1200 | + 5 | ||
| 16-18 | ±1.0 | ±0.30 | 200-2000 | + 20 | ||
| 18-25 | ±1.5 | ±1.0 | ±0.40 | 200-2000 | + 20 | |
| 25-40 | ±2.0 | ±1.5 | ±0.50 | 150-4000 | + 20 | |
| 40-50 | ±2.5 | ±2.0 | ±0.60 | 100-3000 | + 20 | |
| 50-65 | ±3.0 | ±2.0 | ±0.80 | 100-1500 | + 20 | |
